Printhead Technology EPSON DX5/Epson I3200

Colors Double Four Color

Number of Nozzles (180 Nozzles×8 Lines) 1/2 Head as optional

Printing Materials Flex Banner,Vinyl,PVC,Backlit,Canvas,Flag

RIP software Maintop5.3/Photoprint10.5/Onyx

Operating system WindowXP,Win7/8

We're here to help:Easy ways to get the answers you need.

  • Describe
  • Application
  • Parameter
  • Inquiry

1.Double four-color printing,1.6m and 1.80m wide format output
2.Indoor and outdoor ink are both available, meeting different printing needs.
3.Multi-row pinch rollers ensure the machine can print with an accurate size of feeding media.
4.Printing resolution can reach to 1440dpi,even the word is small as 0.5mm.
5.Three different sizes of dots,achieving the complement of images,even under high speed or low resolution

Optional Items
1,Hiwin guide rail,more stable,longer working life,lower noise.
2,Imported dual direction motor,high-resolution driver linear encoder,higher resolution,fewer errors in length,more stable running.
3,Hi USB interface,transmission speed can reach to 480M/S,plug and play conveniently.
4,Adopt EPSON DX5 printhead,variable dots technology,1440DPI high resolution output.
5,VSDT variable droplet techonology,the smallest droplet is 3.5PL,largest droplet is 27PL,achieve the prefect printing quality.
6,Unique two-dimension intelligent eclosion and wave-eclosion function,elimination banding effectively in printing,improveing printing quality obviously.
7,Different kinds of printing mode,reach to 28m per hour in production mode.
8,High quality,clean,pump and moisturize automatically,which can also pump ink well and keep the ink flow fluently.
9,Four large ink reservoirs provide ink durably,keeping wide format high-speed printing wonderfully.
10,Adopt the most recommended ink in advertising industry,achieving fast drying,moisture-proofing and sticky-proofing.

Printhead Epson DX5 micro piezo and stainless steel cartridge Resolution 1440DPI
Number of printhead 2 Number of nozzles 1440(8*180)
Color CMYK Color gamut 16.7 million
Media width 1800mm Printing width 1800mm
Printing speed 4 Pass 30 m2/h
  6 Pass 21 m2/h
  8 Pass 15 m2/h
Ink type Water-based; Eco-solvent based; Sublimation dye Color management ICC based, density & Curves adjustment
RIP software Maintop 5.3/ Wasatch PHOTOPRINT/ ONYX Computer system Win XP, Win 7
Interface USB 2.0 Power supply 50HZ/60HZ, 220V,10A
Heating system Three section heating File forms Bmp, TIF, Jpg, Pdf etc.
Feeding method Roll to roll; Leaf Humidity 40%-70%
Dimension L*W*H: 2600*700*500MM Weight 240KG
