Mesh Belt UV Printer


Printhead I3200-U1

Head Quantity 3

Colors CMYK+W

Ink Type UV ink, eco solvent ink, water based pigment ink

RIP software Maintop, Photoprint, Onyx

Application Leather, PVC Film, Back-lit, Vinyl, etc.

Transport Port Network port

We're here to help:Easy ways to get the answers you need.

  • Describe
  • Application
  • Parameter
  • Inquiry


 This new printer can replaced old UV roll to roll printer, more widely applications:

1. No tension materials--- Vinyl, PVC, little RTR materils

2. Tension materials--- Leather, flim, etc.
Model 1903UV
Printhead Epson I3200-U1*3
Print Width 1800mm
Color CMYK+W
*Tested on linear printing without feather function
6pass 13(m2/h)
8pass 8(m2/h)
Picture Format Bmp, TIF, Jpg, Pdf, etc.
Ink Type UV Ink
Media Back-lit, Film, PET&PVC, Leather
Transmit Port Ethrnet
Feeding Method Roll to Roll, Leaf
Computer Sytem Win7  64bits, Win10  64bits
RIP Software Maintop, Photoprint, Onyx
Power AC220V, 50HZ/60HZ, 10A
Environment 15-30, 35%-65%
Weight 760KG
